Descripción
|
Basic function
|
Position switches | ||
|
Part group reference
|
LLS…ZBZ/X | ||
|
Product range
|
Basic units with spring-powered interlock (closed-circuit principle) | ||
|
Degree of Protection
|
IP65 | ||
|
Features
|
Basic device, expandable | ||
|
Ambient temperature
|
°C | -25 – +40 | |
| Descrption | With interlock monitoring with auxiliary release mechanism Monitoring of door position: continuous |
||
|
Snap-action contact
|
Yes | ||
|
Contacts
|
|||
|
N/O = Normally open
|
1 N/O | ||
|
N/C = Normally closed
|
1 NC  |
||
|
Notes
|
= safety function, by positive opening to IEC/EN 60947-5-1 |
||
| Rated control voltage for magnetic drive [Us ] | 120 V 50/60 Hz V | ||
|
Housing
|
Insulated material | ||
|
Connection type
|
Screw terminal | ||
|
Notes
|
SSwitch must never be used as a mechanical stop! The operating head can be rotated manually in 90° steps without tools to suit the specified level of actuation. With the actuator inserted, the N/O contact is open and the N/C contact is closed. For degree of protection IP65, use V-M20 (206910) cable glands with connecting thread of max. 9 mm length. In the event of power failure (e.g., during commissioning), the device can be released with a screwdriver. The auxiliary release mechanism must be sealed! ￫ Instructional leaflet IL 05208005Z |
