Descripción
|
Product range
|
DILA relays | ||
|
Application
|
Contactor relays | ||
|
Description
|
Basic devices with positive operation contacts | ||
|
Connection technique
|
Screw terminals | ||
|
Rated operational current
|
|||
|
AC-15
|
|||
|
220 V 230 V 240 V
|
Ie | A | 4 |
|
380 V 400 V 415 V
|
Ie | A | 4 |
|
Contacts
|
|||
|
N/O = Normally open
|
2 N/O | ||
|
N/C = Normally closed
|
2 NC | ||
|
Code number and version of combination
|
|||
|
Distinctive number
|
22D | ||
|
Can be combined with auxiliary contact module
|
DILA-XHI(V)… | ||
|
Actuating voltage
|
190 V 50 Hz, 220 V 60 Hz | ||
|
Voltage AC/DC
|
AC operation | ||
|
Instructions
|
Contact numbers to EN 50011 Coil terminal markings to EN 50005 |
